Gas Boiler Spare Parts Steam Boiler Drum Non Toxic High Heating
Efficiency
Description
In the water tube boiler the upper drum (Boiler steam drum)
provides for separation of steam from water. It also provides
liquid holdup capacity (typically 10 to 60 seconds) to allow for a
dynamic response to load changes without losing liquid in the
downcomer and riser tubes. The size of the steam drum is determined
by the volume required for a clean separation between steam and
water to produce a dry saturated steam, it also provides an
adequate amount of steam storage. The steam drum is also called the
upper drum.
Product parameter
| Product Name | Boiler Steam Drum ( Steam Water Separator ) |
| Applied Area | Natural circulation boiler |
| Drum Shell Plate Material | - Carbon Steel : Q245R, P265GH, SA516-Gr.60/65/70 - Alloy Steel : Q345R, Q375R, 15CrMoR, 12Cr1MoVR, P355GH , DIWA353 |
| Drum Head Material | Same as shell |
| Nozzle Tube Material | As per design |
| Standard | China GB, ASME, EN |
| Manufacturer Grade | China A Grade, ABS Certificated, TUV Certificated |
| Working Temperature | Saturation Temperature at rated pressure |
| Working Pressure | 1.6 MPa ~ 22.5 MPa |
Shell Plate Thickness (Drum Wall Thickness) | ≤150 mm |
| Drum Diameter | ≤3,200 mm |
| Drum Length | ≤25,000 mm |
| Welding | - Shell : SMAW, SAW - Nozzle tube : GTAW (TIG), SMAW |
| Welding NDT | - Shell longitudinal seam : 100% RT, 100% UT - Shell circumferential seam : 100% RT, 15% UT - Nozzle tube angle seam : 100% UT, 100% MT |
Boiler Parts
Boiler Super Heater,Boiler High Temp Superheater,Boiler Cyclone
Separator,Boiler Flue,Boiler Heat Pipe Air Preheater,Boiler Gen
Bank,Boiler Heat Pipe Elements,Boiler Tube Pin,Boiler
Tubeshield,Boiler Ditch Tube
Suzhou ORL Power Engineering Co., Ltd.is located in Suzhou, Jiangsu
Province.
ORL Power is a leading company and exporter of industrial
boilers,power plant boilersand boiler parts (including steam drum,
membrane waterwall panel,header,economizer, evaporator,
superheater,H-fin economizer, spiral fin tube, air preheater, heat
pipe, flue etc.), seamless steel tubes/pipes and ERW steel
pipes.ORL provides our customer with full range of services
including boiler design, fabrication, installation and
commissioning, boiler maintenance, and supervision at site. Our
product and service include design and manufacture industrial
boilers, pressure vessels and tanks, and pressure parts for power
plant boilers (600MW, or 1000MW).
Company Information
Product Description
Production Workshop
Boiler Product Production
Boiler Cyclone Separator WorkShop, Boiler Coil Workshop, Boiler
Waterwall Workshop.
Testing Center
Boiler Product Test
Impact test,The scene to examine the water-wall,Industrial TV
monitoring,Snake-like pipe water pressure test,Header endoscopic
detection,Header weld inspection
Packaging & Shipping
Certifications
Company Business
Our products have been wildly used in power plants and large
international companies overseas.
Such as USA, Brazil, Porto Rico, Guatemala, Spain, Demark, Norway,
Turkey, India, Korea, Australia, Middle East, Southeast Asia etc.
We have our boiler manufacturing plant, and obtain ISO9001:2008,
ISO3834, ASME S, U and GB stamp.
Trading Process
ORL offers prompt response, professional products, and all-around
service to our customers. Our experienced sales team and engineers
are waiting for your enquiry and ready to provide sincere service.
We cordially welcome domestic and overseas friends to visit our
company and manufacturing bases, and look forward to building up
long-term, mutual cooperative relationship with you.
FAQ
1. Why choose us?
We are boiler and boiler parts(boiler drum, boiler waterwall panel,
boiler economizer, boiler header, boiler cyclone separator, boiler
flue pipe, boiler air preheater, boiler pipe, boiler
tube)manufacture and we are one of the best suppliers in China.
We ensure the deliver time, high quality, and the best after-sale
service for you.
2. How to order?
Welcome come to our factory for inspecting and discussion the
technical details.
